Description

The Druck Genii DPI 620G IS-L is an intrinsically safe multifunction calibrator designed specifically for use in hazardous areas. Compact, powerful, and versatile, it combines multiple calibration tools into one rugged handheld device, eliminating the need to carry several instruments into the field.

Key Features:

1. Intrinsically Safe Design: Certified for use in hazardous (Ex-rated) environments.
2. Multifunction Capability: Calibrates pressure, temperature, and electrical signals in one device.
3. Electrical Measurement & Simulation: Measures and sources mA, mV, V, resistance, frequency, and switch states.
4. HART, Fieldbus, and Profibus Communication (Optional): Integrated communicator for smart transmitter configuration and diagnostics.
5. Modular Pressure System: Compatible with Druck pressure modules (PM620, PM700, etc.), extending the range from low differential to high pressure up to 1000 bar.
6. Automated Calibration Routines: Streamlines calibration tasks and ensures consistency.
7. High Accuracy & Stability: Delivers laboratory-grade performance in a portable, field-ready design.
8. Touchscreen Interface: Bright, intuitive color display with advanced navigation.
9. Rugged & Portable: Battery-powered, lightweight, and built for harsh process environments.

Standard Accessories (Included):

• Rechargeable lithium polymer battery (P/N IO620-BATTERY)
• Universal mains adapter/charger (P/N IO620-PSU)
• AC measurement probe, P/N IO620-AC (300 VAC true RMS)
• Test leads
• Calibration certificate
• Quick reference guide
