Description

The Druck Genii DPI 620G is a high-performance advanced modular multifunction calibrator designed for electrical, temperature, and pressure calibration in one compact handheld device. With integrated HART communication, it provides a complete solution for process calibration, configuration, and maintenance tasks.

Key Features:

1. Pressure Measurement Range: 25 mbar to 1000 bar (with interchangeable Druck pressure modules).
2. Multifunction Capability: Calibrates pressure, electrical signals (mA, mV, V, Ω, frequency), and temperature.
3. HART Communication: Built-in communicator for configuring and diagnosing smart transmitters.
4. Advanced Modular Design: Compatible with Druck pressure modules (PM620, PM700, etc.) for flexible expansion.
5. Automated Calibration Routines: Saves time and ensures consistent accuracy.
6. High Accuracy & Stability: Laboratory-grade performance in the field.
7. Touchscreen Interface: Intuitive color display with modern navigation.
8. Rugged, Portable & Battery-Powered: Built for tough industrial environments.

Standard Accessories (Included):

• Rechargeable lithium polymer battery (P/N IO620-BATTERY)
• Universal mains adapter/charger (P/N IO620-PSU)
• AC measurement probe, P/N IO620-AC (300 VAC true RMS)
• Test leads
• Calibration certificate
• Quick reference guide
